0086-15951185209 LLGZ Flat Plate Large Clamshell Automatic Scraper Bag-pulling Discharge Centrifuge
Product Features:
1. It adopts variable frequency control, ensuring smooth startup and allowing adjustment of the separation factor.
2. The system is controlled by PLC (Programmable Logic Controller), with program settings. The entire process, including feeding, initial filtration, washing, fine filtration, discharging, and filter cloth regeneration (removal of residual filter cake), is automatically controlled. All processes can operate according to the pre-set program as per the customer's requirements.
3. The structural components of the entire machine are smoothly and evenly rounded, effectively eliminating any potential hygiene blind spots; the flip cover adopts a butterfly-shaped structure, with good rigidity and strength.
4. The feeding adopts an independent type of inclined disc feeding method. The feeding speed is adjustable. The feeding rotation speed is asynchronous with the drum rotation speed. Especially for crystalline substances with better dehydration performance and larger particle size, it can reduce or eliminate the vibration caused by uneven feeding.
5. The platform-type four-point suspension vibration reduction system employs high-viscosity liquid damping dampers and large inertia balancing plates, achieving outstanding vibration reduction performance.
6. The large flip-cover design makes it easier to perform machine maintenance and replace the filter cloth.
7. The structure is sealed, and the sealing components are made of silicone rubber or fluorine rubber. This design can prevent toxic and highly corrosive materials from leaking and causing harm to people, ensuring a high level of safety.
8. Utilizing an integrated mechanical and electrical material detector, it offers excellent reliability.
9. Energy consumption braking, a non-contact braking method, without frictional dust pollution;
10. Safety protection: Lid opening protection, vibration over-limit protection device, air pressure protection device, motor overload protection
Thermal protection device, scraper rotation (lifting and lowering) is controlled by both mechanical and electrical means.
11. Install a residual filter cake removal device: After the scraper removes the material, the cylinder is used to pull the filter bag to remove the residual filter cake, thus avoiding secondary pollution.
12. With a reliable self-locking and convenient bag-fixing method, the filter bag replacement can be completed quickly.
Standard configuration:
1. The outer shell adopts a large flip cover design, equipped with a scraper device, a slanted plate fabricating device, an explosion-proof lighting fixture, a quick-opening manhole, an inlet pipe, and a washing pipe.
2. It is equipped with a regular motor or an explosion-proof motor.
3. It is equipped with a PLC device-based variable frequency control system and a non-contact braking system.
4. It is equipped with an air control station and a hydraulic control station.
5. It is equipped with an integrated mechanical and electrical material detector.
Optional Equipment:
1. Nitrogen protection device;
2. Over-vibration protection device;
3. Online cleaning device;
4. Gas-assisted scraper device;
5. Opening cover protection device;
6. High-pressure gas backflush device;
7. Pneumatic or hydraulic butterfly valve for discharging gas;
8. Select the corresponding material according to the anti-corrosion requirements of the separated materials: stainless steel 304, 316, 316L, 321, etc., titanium material or carbon steel with plastic coating, rubber lining, or Halar lining.
Scope of Application:
This centrifuge is not only suitable for solid-liquid separation of general media, but also for solid-liquid separation of media with poor fluidity and poor spreading performance. It has better adaptability to materials and is applicable in industries such as pharmaceuticals, food, and chemicals.
Product parameters:
|
Project |
型号 |
||||
|
LLGZ1200 |
LLGZ1250 |
LLGZ1400 |
LLGZ1500 |
LLGZ1600 |
|
|
Inner diameter of the drum(mm) |
1200 |
1250 |
1400 |
1500 |
1600 |
|
Effective height of the drum(mm) |
455 |
615 |
720 |
710 |
750 |
|
Baffle plate diameter(mm) |
900 |
900 |
1000 |
1100 |
1100 |
|
Rotary drum volume(L) |
250 |
400 |
600 |
650 |
850 |
|
Filtering area(m²) |
1.71 |
2.4 |
3.2 |
3.34 |
3.8 |
|
Maximum loading limit(kg) |
325 |
520 |
600 |
845 |
1105 |
|
Rotary drum speed(r/min) |
1000 |
1000/1200 |
945 |
850 |
850 |
|
Factorization |
673 |
700/1006 |
700 |
609 |
648 |
|
Motor power(Kw) |
18.5 |
22 |
30 |
30 |
45 |
|
Overall dimensions (L×W×H)mm |
2400*1800*2360 |
2400*1800*2770 |
2600*2000*3050 |
3000*2400*3055 |
3000*2400*3225 |
|
Machine weight(kg) |
≈4800 |
≈6500 |
≈7800 |
≈11500 |
≈12500 |
