0086-15951185209 LLGZ Flat Plate Large Clamshell Automatic Scraper Bag-pulling Discharge Centrifuge
Main features:
1. Utilizing variable frequency control, the startup is smooth, and the separation factor can be adjusted;
2. The structure is simple, operation is convenient, and the operation procedures such as feeding, initial filtration, washing, and fine filtration can be adjusted arbitrarily according to requirements;
3. The material grains are not easily broken, and the adaptability is strong;
4. Manual bottom discharge reduces labor intensity and improves production efficiency;
5. The machine base is of a flat plate structure, which not only lowers the center of gravity of the machine, making the machine operation more stable, but also the flat plate machine base can be used as an operation platform, making the operation more convenient;
6. Equipped with a high viscosity liquid damping shock absorber, it can more effectively eliminate vibrations and simplify daily maintenance.
Standard configuration:
1. Open design of the shell;
2. Equipped with a regular motor or explosion-proof motor;
3. Equipped with a variable frequency control system and a non-contact braking system;
4. Equipped with a liquid damping shock absorber;
Optional Equipment:
1. The small flip cover device is equipped with explosion-proof lighting, feed pipe, washing pipe and observation sight glass.
2. Over-vibration protection device.
3. On-site explosion-proof button.
4. Select the corresponding material according to the anti-corrosion requirements of separating materials: stainless steel 304, 316, 316L, 321, etc., titanium material or carbon steel with plastic coating, rubber coating, or Halar coating on the surface.
Technical Specifications:
Model |
Basket | Separation factors (DW2/2g) | Motor power(Kw) | Overall weight of the machine (Kg) |
Dimensions of the shape (L×W×H)mm | |||
| Diameter(mm) | Working volume(L) | Loading weight limit(Kg) | Speed(r/min) | |||||
| PX800 | 800 | 90 | 140 | 1200 | 645 | 5.5 | 1800 | 1800×1200×950 |
| PX1000 | 1000 | 160 | 200 | 1000 | 560 | 7.5 | 2800 | 2000×1400×1000 |
| PX1200 | 1200 | 260 | 330 | 900 | 544 | 11 | 3400 | 2400×1700×1350 |
| PX1250 | 1250 | 300 | 400 | 900 | 567 | 15 | 3600 | 2400×1700×1350 |
