0086-15951185209 LLGZ Flat Plate Large Clamshell Automatic Scraper Bag-pulling Discharge Centrifuge
Main features:
1. Utilizes variable frequency control, with smooth startup and adjustable separation factors;
2. Uses PLC control, with program settings, automatic control throughout the process of feeding, initial filtration, washing, fine filtration, and discharging;
3. The base and casing are of an integral welding structure, with high bearing strength;
4. The base is of a flat structure, which not only lowers the center of gravity of the machine, making its operation more stable, but also the flat base can be used as an operation platform, making operation more convenient;
5. Equipped with high-viscosity liquid damping shock absorbers, more effectively eliminating vibrations, simplifying daily maintenance;
6. Enclosed structure, using silicone rubber or fluororubber seals, can prevent toxic and highly corrosive materials from leaking and injuring people, with a high safety factor;
7. Uses an integrated material detector for electromechanical system, with good reliability;
8. Energy consumption braking, non-contact braking method, without friction dust pollution;
9. Safety protection: motor overload and overheating protection, scraper rotation, lifting mechanical and electrical dual control, scraper and drum interlocking protection.
Standard configuration:
1. The shell has a flat cover design, equipped with explosion-proof lighting fixtures, observation visor, feed pipe, and washing pipe;
2. Equipped with a regular motor or explosion-proof motor;
3. Equipped with a PLC device's variable frequency control system and non-contact braking system;
4. Equipped with a hydraulic station;
5. Equipped with an integrated mechanical and electrical material detector;
6. Equipped with a liquid damping shock absorber;
Optional configurations:
1. Nitrogen protection device;
2. Over-vibration protection device;
3. Online cleaning device;
4. Gas-assisted scraper device;
5. High-pressure gas backflush device;
6. Pneumatic or hydraulic butterfly valve for discharging;
7. Pneumatic or hydraulic ball valves for the inlet pipe and washing pipe;
8. On-site explosion-proof operation box;
9. Select the corresponding material according to the anti-corrosion requirements of the separated materials: stainless steel 304, 316, 316L, 321, etc., titanium material or carbon steel with plastic coating, rubber lining, or Halar coating on the surface.
Technical Specifications:
Model |
Basket | Separation factors (DW2/2g) | Motor power(Kw) | Overall weight of the machine (Kg) |
Dimensions of the shape (L×W×H)mm | |||
| Diameter(mm) | Working volume(L) | Loading weight limit(Kg) | Speed(r/min) | |||||
| PGZ800 | 800 | 90 | 140 | 1200 | 645 | 7.5 | 2000 | 1800×1200×2150 |
| PGZ1000 | 1000 | 160 | 200 | 1000 | 560 | 11 | 2800 | 2000×1400×2350 |
| PGZ1200 | 1200 | 260 | 330 | 900 | 544 | 15/18.5 | 4200 | 2400×1800×2600 |
| PGZ1250 | 1250 | 300 | 400 | 900 | 567 | 18.5/22 | 4300 | 2400×1800×2600 |
| PGZ1500 | 1500 | 540 | 680 | 800 | 538 | 30 | 7000 | 2600×2200×2800 |
