0086-15951185209 LLGZ Flat Plate Large Clamshell Automatic Scraper Bag-pulling Discharge Centrifuge
Main features:
1. Utilizes variable frequency control, with smooth startup and adjustable separation factors;
2. Controlled by PLC, with program settings, the entire process of feeding, initial filtration, washing, fine filtration, and discharging is automatically controlled;
3. The machine shell adopts a welded structure, with a compact design and high machine bearing strength;
4. The motor is installed together with the centrifuge main unit, facilitating installation and use, and reducing the machine's occupied space;
5. Enclosed structure, using silicone rubber or fluorine rubber for sealing, can prevent toxic and highly corrosive materials from leaking and injuring people, with a high safety factor;
6. Independent hydraulic station, can be installed separately, facilitating maintenance;
7. Safety protection: vibration protection device, motor overload and overheating protection, electrical dual control for scraper rotation, and interlocking protection between the scraper and the drum;
8. Design of vibration isolation device and rubber vibration-damping foundation, the machine operates smoothly, vibration and noise are significantly reduced, improving the production space and working environment, and reducing the harm of machine vibration to equipment and the environment;
9. The internal parts of the centrifuge in contact with the materials are all made of corrosion-resistant stainless steel, improving the equipment's corrosion resistance;
10. Optional spiral conveyor for discharging (GK1250-N type and above models), for materials with poor slippage, can effectively prevent blockage.
Working principle:
The horizontal scraper discharge centrifuge is a continuous operation, intermittent operation filtering centrifuge. Its control mode is automatic control, and it can also be changed to manual control. Different from ordinary vertical centrifuges, the entire working process of this centrifuge, including feeding, separation, washing, dehydration, discharging and filter cloth regeneration, is completed at high speed. Therefore, its single working time is short, the processing capacity is large, and it can obtain drier filter residues and good washing effects.
Technical Specifications:
Model |
Basket | Separation factors (DW²/2g) | Motor power(Kw) | Overall weight of the machine (Kg) |
Dimensions of the shape (L×W×H)mm | |||
| Diameter(mm) | Working volume(L) | Loading weight limit(Kg) | Speed(r/min) | |||||
| GK800N | 800 | 80 | 120 | 1500 | 1008 | 30 | 5500 | 2500×1600×1800 |
| GK1000N | 1000 | 172 | 240 | 1350 | 1023 | 37 | 8500 | 2800×1800×2000 |
| GK1250N | 1250 | 340 | 425 | 1200 | 1008 | 55 | 130000 | 3820×2450×2100 |
